Why use models?

We need a model to relate what we observe (data) to what we want to know (hypotheses and parameters).

We almost invariably choose probabilistic models for molecular evolution, because we don't know enough about mutation to construct a deterministic model.

Modelling genetic change

• Given two or more aligned nucleotide or amino acid sequences, usually the first goal is to calculate some measure of sequence similarity (or conversely distance).
• The easiest distance to compute is the p-distance: the number of differences between two aligned sequences relative to their length.
  • The p-distance is the Hamming distance normalized by the length of the sequence. Therefore it is the proportion of positions at which the sites differ.
  • The p-distance can also be considered the probability that the two sequences differ at a random site.

Modelling genetic change

p-distance

$p$-distance = 3/7 $\simeq 0.43$.

• Proportion of differences between two sequences.
• Usually underestimates the true distance: genetic (or evolutionary) distance $d$.

Multiple, parallel and back-substitutions

Relationship between $p$-distance and genetic distance

Continuous-time Markov chains (CTMCs)

• CTMCs are the continuous-time generalization of Markov chains
• state $X(t)$ is a function of a continuous time parameter.
• Obey the Chapman-Kolmogorov equation: $$P(X(t_1)|X(t_0))=\sum_{X(t_i)}P(X(t_1)|P(X(t_i))P(X(t_i)|P(X(t_0))$$
Informally: you can find the probability of going from state $X(t_0)$ to $X(t_1)$ by averaging over all intermediate states $X(t_i)$ at intermediate time $t_i$.

CTMC Mathematical Details (Optional)

This section is intended for mathematically-inclined individuals.

• Can be written in the following differential form: \begin{align*} \frac{d}{dt}p(x,t|x_0,t_0)&=\sum_{x'\neq x}\left[p(x',t|x_0,t_0)Q_{x'x}-p(x,t|x_0,_0)Q_{xx'}\right]\\ &=\sum_{x'}Q_{x'x}p(x',t|x_0,t_0) \end{align*} defining $Q_{xx}=-\sum_{x'\neq x}Q_{xx'}$.
• This form is known as the Master Equation or Kolmogorov forward equation. Linear, so solution is "simply" $\vec{p}(t)=\exp[Qt]\vec{p}(0)$.

Relationship between Q and P in CTMCs

Instantaneous Rate Matrix $Q$

• Describes rates of character changes in an infinitesimal time interval
• Characters can be nucleotides or amino acids
• Diagonal elements are defined such that the sum of each row is zero

Transition Probability Matrix $P(t)$

• Describes probabilities of character changes over time interval t
• Elements are probabilities of observing a specific character at time t, given the starting character at time 0

Relationship between $Q$ and $P(t)$

$P(t) = exp(Qt)$, where $exp(Qt)$ is the matrix exponential of the product of $Q$ and $t$

• If you know the instantaneous rates (Q), you can calculate the probabilities over any time interval $t$ using the matrix exponential
• Matrix exponential can be calculated using eigenvalue decomposition or Taylor series expansion

Stationary Distribution

• As $t$ approaches infinity, $P(t)$ converges to the stationary (or equilibrium) distribution.
• Represents long-term probabilities of observing each character, independent of the starting character.

CTMC example

Consider a system with two states (0 and 1) and a transition rate matrix $$Q = \left[\begin{array}{cc} - & 2 \\ 1 & - \end{array}\right]$$

Gives rise to the following trajectories:

Time $\Delta t$ spent in state before transition: $$ P(\Delta t|x) = \lambda e^{-\lambda \Delta t}$$ where $\lambda = \sum_{x'\neq x}Q_{xx'} = -Q_{xx}$.

Time-reversible CTMCs and detailed balance

A CTMC is time-reversible if and only if it satisfies the property: \begin{equation} \pi_iQ_{ij} = \pi_jQ_{ji}, \end{equation}

or equivalently the detailed balance property: $$\pi_iP_{ij}(t) = \pi_jP_{ji}(t).$$

From this it can be shown that a CTMC is time-reversible iff there exists a row-vector of state probabilities $\Pi$ such that: \begin{equation} \Pi Q = 0 \end{equation}

Consider again a system with two states (0 and 1) and a transition rate matrix: $$Q = \left[\begin{array}{cc} -2 & 2 \\ 1 & -1 \end{array}\right]$$

Then it is easy to show that $\Pi = [\frac{1}{3}, \frac{2}{3}]$ is a solution, so that this CTMC is time-reversible and $\Pi$ is the equilibrium distribution over states.

From rates to probabilities: matrix exponential

Transition probability matrix is the matrix exponential of the instantaneous rate matrix:

\[ P(t) = \exp(Q t) = \sum_{k = 0}^{\infty} \frac{ (Q t)^k}{k!} = \mathbf I + tQ + \frac{(t \mathbf Q)^2}{2} + \frac{(t \mathbf Q)^3}{6} + \ldots\]

Can sometimes calculate analytically

For general \(Q\), use numerical methods from numerical libraries.

The matrix exponential follows the rules we would hope for the exponential function. For example:

• \(\exp(\mathbf 0) = \mathbf I_n\)
• when \(\mathbf{AB} = \mathbf{BA}\), \(\exp(\mathbf{A+B}) =\exp(\mathbf{A})\exp(\mathbf{B})\)
• When \(\mathbf B\) is invertible, \(\exp(\mathbf{BAB}^{-1}) = \mathbf{B}\exp(\mathbf{A})\mathbf B^{-1}\)
• If \(\mathbf A = \mathrm{diag}(a_1,\ldots,a_n)\), then \(\exp(\mathbf A) = \mathrm{diag}(\exp(a_1),\ldots,\exp(a_n))\).

Matrix exponential example

Suppose there are two states, 0 and 1.

Let the rate matrix be

\[Q = \renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cc} -1 & 1 \\ 0.6 & -0.6 \end{array} \right].\]

To get the probability matrix, use the matrix exponential:

\[ P(1) = \exp(1.Q) = \mathbf I + Q + \frac{ \mathbf Q^2}{2} + \frac{ \mathbf Q^3}{6} + \ldots = \renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cc} 0.501 & 0.499 \\ 0.299 & 0.701 \end{array} \right] \]

So if we started in state 1 at time 0, at time 1 there is a 29.9% chance of being in state 0 and a 70.1% chance of being in state 1.

Matrix exponential example

By time 2, the preference for state 1 is obvious:

\[ P(2) = \exp(2Q) = \renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cc} 0.400 & 0.600 \\ 0.360 & 0.640 \end{array} \right] \]

Remember, can calculate for any value of \(t\), not just integers:

\[ P(0.234) = \exp(0.234 \times Q) = \renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cc} 0.805 & 0.195 \\ 0.117 & 0.883 \end{array} \right] \]

Matrix exponential example

If we ran it for an infinitely long period of time, get the same probabilities regardless of start state:

\[ P(\infty ) =\renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cc} 0.375 & 0.625 \\ 0.375 & 0.625 \end{array} \right] \]

Each row is a copy of the equilibrium distribution or stationary distribution for the process.

Want this property of stationarity for models of DNA substitution so that

\[ P(\infty ) =\renewcommand{\arraystretch}{1.25} \left[ \begin{array}{cccc} \pi_A & \pi_C & \pi_G & \pi_T \\ \pi_A & \pi_C & \pi_G & \pi_T \\ \pi_A & \pi_C & \pi_G & \pi_T \\ \pi_A & \pi_C & \pi_G & \pi_T \end{array} \right] \]

\(\pi = [\pi_A , \pi_C , \pi_G , \pi_T]\) is the stationary distribution of the bases.

Jukes-Cantor model of nucleotide substitution

$$ Q = \mu\left[\begin{array}{cccc} -1 & \frac{1}{3} & \frac{1}{3} & \frac{1}{3}\\ \frac{1}{3} & -1 & \frac{1}{3} & \frac{1}{3}\\ \frac{1}{3} & \frac{1}{3} & -1 & \frac{1}{3}\\ \frac{1}{3} & \frac{1}{3} & \frac{1}{3} &-1 \end{array}\right] $$

Differences per site

Genetic distance under Jukes-Cantor

The probability that a site is distinct after time $t$ is \begin{align*} p_{\text{diff}}&=\sum_{x'\neq x} P(X(t)=x'|X(0)=x)\\ &=\frac{3}{4} - \frac{3}{4}e^{-\frac{4}{3}\mu t} \end{align*}

Equating $p_{\text{diff}}$ with the $p$-distance and solving for $\mu t$ yields $$\hat{d} = \widehat{\mu t} = -\frac{3}{4}\log(1-\frac{4}{3}p).$$

Other CTMC substitution models: Kimura 80

$$ Q = \left[\begin{array}{cccc} \cdot & \alpha & \beta & \beta \\ \alpha & \cdot & \beta & \beta \\ \beta & \beta & \cdot & \alpha \\ \beta & \beta & \alpha &\cdot \end{array}\right] $$

• Also "Kimura two parameter" model.
• Allows different rates for transitions and transversions.
• Equilibrium base frequencies equal.

Other CTMC substitution models: HKY

$$ Q = \left[\begin{array}{cccc} \cdot & \alpha\pi_G & \beta\pi_G & \beta\pi_G \\ \alpha\pi_A & \cdot & \beta\pi_A & \beta\pi_A \\ \beta\pi_C & \beta\pi_C & \cdot & \alpha\pi_C \\ \beta\pi_T & \beta\pi_T & \alpha\pi_T &\cdot \end{array}\right] $$

• Due to Hasegawa, Kishino, Yano (1985).
• Allows different transition transversion rates.
• Allows equilibrium base frequencies to differ.
• Most complex model for which analytical solutions are available.

Other CTMC substitution models: GTR

$$ Q = \left[\begin{array}{cccc} \cdot & \alpha\pi_G & \beta\pi_G & \gamma\pi_G \\ \alpha\pi_A & \cdot & \delta\pi_A & \epsilon\pi_A \\ \beta\pi_C & \delta\pi_C & \cdot & \eta\pi_C \\ \gamma\pi_T & \epsilon\pi_T & \eta\pi_T &\cdot \end{array}\right] $$

• All models so-far have been reversible.
• GTR is the most general time-reversible model.
• Reversibility is a mathematical convenience: no biological reason!
• No useful analytical solution available (matrix exponential doesn't count).

Variable rates among sites

Genetic distance variation between models

• HIV-1B vs HIV-O/SIVcpz/HIV-1C: env gene:

  	$p$-distance	JC69	K80	Tajima-Nei
  HIV-O	0.391	0.552	0.560	0.572
  SIVcpz	0.266	0.337	0.340	0.427
  HIV-1C	0.163	0.184	0.187	0.189

• HIV-1B vs HIV-O/HIV-1C: pol gene:

  	$p$-distance	JC69	K80	Tajima-Nei
  HIV-O	0.257	0.315	0.318	0.324
  HIV-1C	0.103	0.111	0.113	0.114
